Tektronix GeoProbe G10 User Manual

G10 Hardware Maintenance Guide 7.13.2 70 
3
Blades and RTMs
Rev. 002-140228
SSD-3400 RTM
The IAP100 also supports an SSD-3400 RTM. This RTM is the same blade as the PRM100
RTM except it provides an 80 GB SSD system disk (Figure 3.38). The RTM supports serial,
USB, and SAS ports.
Figure 3.38 - SSD-3400 RTM
10G INTERCONNECT CARD
The 10G Interconnect card (Figure 3.39) provides additional 10G Ethernet connectivity
directly to both of the blades in the cage. Two 10
G Interconnect cards are required to support
Deep Packet Classification (DPC). Refer to 10G Interconnect Card for installation and removal
procedures.
Figure 3.39 - G10 Chassis Rear - 10G Interconnect Cards
10G Interconnect Cards
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
