Tektronix GeoProbe G10 User Manual

G10 Hardware Maintenance Guide 7.13.2 53 
3
Blades and RTMs
Rev. 002-140228
APPLICATIONS BLADE
The Applications Blade provides the following functions for the G10 probe:
 Performs analysis, correlation, and processing functions
 Controls the OS for GeoProbe G10
 Provides the Ethernet connection to customer LAN
 Enables S2D functionality (LT and ST)
Iris currently supports the following applications blades:
 IAP320/IAP200
 IAP100
GbE Activity GREEN
Gb Ethernet Activity LEDs which indicate the status of
the traffic running over the connection.
 BLINKING GREEN—Ethernet activity occurring.
 SOLID GREEN—Ethernet link is up.
 OFF—no Ethernet link established.
ACT (SAS) GREEN or RED
Indicates SAS activity.
 GREEN—no errors, SAS link is up.
 RED—error occurred.
 OFF—no SAS link established.
Table 3.14 - TRM100 RTM LED Indicators (Continued)
Connect
or/LED LED Color Description
