Tektronix GeoProbe G10 User Manual

G10 Hardware Maintenance Guide 7.13.2 34 
3
Blades and RTMs
Rev. 002-140228
IIC200
The Iris Interface Card (IIC200) consists of the following components (Figure 3.3):
 AMC ATCA carrier card (CAB100)
 FPC200 AMC
 LPC200 AMC
Figure 3.3 - G10 IIC200
IIC200 LEDs
The four LEDs visible from the left side of the IIC200 front panel are part of the CAB100 carrier
blade (Figure 3.3). Refer to the IIC LEDs section for details.
LPC200 AMC FPC200 AMC
Iris Interface Card (IIC200)
IIC
LEDs
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
