G10 Hardware Maintenance Guide 7.13.2 116 
5
Maintenance Guidelines
Rev. 002-140228
RTMs
Perform the following to reset or remove an RTM.
Step Action
1. Depending on which RTM you are removing, power down the associated
blade first:
 SRM200 RTM—Power down the IIC200 first. Refer to Removing or
Resetting the IIC100 or IIC200.
Media Probe Configurations Only: If replacing an SRM200 RTM during maintenance,
you must verify the J8 jumper setting is TERMINATED prior to installation (see the
Media Probe Installation Guide for details).
 SRM100 RTM—Power down the IIC100 first. Refer to Removing or
Resetting the IIC100 or IIC200.
 TRM100 RTM—Power down the IIC100 first. Refer to Removing or
Resetting the IIC100 or IIC200.
 PRM100—Power down the IAP100 first. Refer to Removing or Resetting
the IAP100.
 PRM200—Power down the IAP200 first. Refer to Removing or Resetting
the IAP200/IAP320.
 PRM300—Power down the IAP320 first. Refer to Removing or Resetting
the IAP200/IAP320.
2. When the associated blade’s Hot Swap LED is solid blue, its OS has powered
dow
n
completely.
3. Pinch the latch and lever on the RTM right ejector
handle and pull the handle
outward slightly. The blue Hot Swap LED starts to blink.
