G10 Hardware Maintenance Guide 7.13.2 85
4
Storage Subsystem
Rev. 002-140228
Expansion Enclosure Connectors
Table 4.7 displays the expansion disk enclosure connectors. Refer to the G10 Installation
Guide for more information about how the G10 conn
ects to the storage enclosures.
Fault/Service Required This LED displays the color AMBER. A fau
lt is detected or a service
action is required. Hardware controlled power-up or a cache flush or
restore error. Valid options are:
ON—A fault has been detected or a service action is required.
BLINKING—A hardware-controlled power-up, cache flush, or
restore error.
OK to Remove Not Implemented
OK This LED displays the color GREEN. Valid options are:
ON—The expansion module is operating normally.
BLINKING—The system is booting.
OFF—The expansion module is not OK.
Service Port Used only by service personnel.
SAS in Status This LED displays the color GREEN. Valid options are:
ON—The port is connected, and the link is up.
OFF—The port is empty, or the link is down.
SAS out Status This LED displays the color GREEN. Valid options are:
ON—The port is connected, and the link is up.
OFF—The port is empty, or the link is down.
Table 4.6 - Expansion Disk Enclosure
LEDs (Continued)
LED Description
Table 4.7 - Expansion Disk Enclosure Connectors
Connector Description
Service Port Used only by service personnel.
SAS Out Port Connects to another drive enclosure.
SAS In Port Connects to another drive enclosure.
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
