G10 Hardware Maintenance Guide 7.13.2 159
A
Rev. 002-140228
INSTALLING SFPS
You can install and remove/replace SFPs without powering down the probe or blade. Perform
the following steps to install or remove/replace SFPs.
Step Action
1. Perform one of the following:
New SFPs: Remove the filler plugs from the sockets on the blades where
the SFPs will be installed. Keep the filler plugs in place for any unused or
empty sockets to protect the sockets and to control airflow.
Replacing SFPs: Remove cabling from the SFPs that will be replaced.
Open the handle on the SFP and remove it by pulling it gently out of the
socket.
2. Make sure the new/replacement SFP’s handle i
s
in the closed position. This ensures
that the SFP snaps into position when inserted into the socket. Also, keep the SFP
filler plug in place until the SFP is installed.
3. Determine the correct orientation for the SFP you are inserting. SFP orientation varies
de
pen
ding on the blade and port in which you are installing it. Refer to the following
sections for orientation details:
4. Carefully slide the SFP into the socket until its connector is fully seat
ed and snaps into
position. Keep the filler plugs in place until you are ready to connect cables to the
SFPs. The plugs protect the SFP internal components.
5. Connect cabling.
6. If this is a new installation, you must config
ur
e the Physical Device Port settings in
Probe Details tab in Iris Admin. Refer to the Iris Admin online help for details.
If replacing SFPs, procedures vary depending o
n
the type of SFP replacement you
are performing and the blade in which you are replacing it. Table A.2 summarizes the
required steps for each scenario.
IIC200 PRM200 RTM or PRM300 RTM
IIC100 SRM200 RTM
TRM100 RTM
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
