G10 Hardware Maintenance Guide 7.13.2 60
3
Blades and RTMs
Rev. 002-140228
Table 3.17 provides descriptions of the IAP200 connectors.
PRM300 RTM/PRM200 RTM
The IAP320 supports the PRM300 RTM; and the IAP200 supports the PRM200 RTM. These
RTMs have the same connectors and LEDs.
The RTM provides additional connectivity options and a hard disk used for the operating
system. The R
TMs connect to the rear of the respective IAP. The RTM performs the following
functions:
Provides cable connections to the disk array
Provides hard drive for operating system
Includes an IPMC
Table 3.19 - IAP200 Connectors
Connector Description
ETH Connector Used during initial probe configuration; not used during normal
pr
ob
e operation.
Serial Console Port Enables an RJ-45 cable to connect to an external computer to
di
splay and interact with the CPM’s software. In order to
communicate with the CPM, the terminal emulator on the
external computer must match the default settings for the CPM
serial port:
28800 bps
no parity
8 data bits
1 stop bit
no flow control
For best display results, the terminal should be set to 80
columns by 25 lines.
USB 1–2 These connectors are a standard USB 2.0 used for service and
m
a
intenance.
