G10 Hardware Maintenance Guide 7.13.2 102
5
Maintenance Guidelines
Rev. 002-140228
G10 Blade Removal/Replacement Procedures
Before removing any G10 blades or RTMs, contact Tektronix Communications
Customer Support.
Prior to hardware upgrades/downgrades, the Iris server and G10 probe MUST:
Have the minimum software version required for the installed blades. Contact
Tektronix Communications Customer Support for assistance.
Be on the same version of software; Iris server version must match G10 probe
version.
This section provides procedures for the following G10 blades and RTMs.
IAP100
This section contains the following procedures for the IAP100.
Removing or Resetting the IAP100
Installing the IAP100
Removing or Resetting the IAP100
Perform the following to reset or remove the IAP100.
Step Action
1. Pinch the latch and lever on the right ejector handle and pull the handle outward
slightly as shown (Figure 5.15).
Procedures For: Refer to Page:
IAP100 page 102
SAS AMC (IAP100) page 105
IAP200/IAP320 page 106
Iris Interface Card (IIC100 or IIC200) page 108
LPC and FPC AMCs (IIC100 or IIC200) page 115
RTMs page 116
10G Interface Card page 118
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
