G10 Hardware Maintenance Guide 7.13.2 80
4
Storage Subsystem
Rev. 002-140228
6 Gb SAS Activity Status These LEDs display the color GREEN. Valid options are:
BLINKING—The link has I/O activity.
OFF—The link is idle.
6Gb SAS Link Status These LEDs display the color GREEN. Valid options are:
ON—The port is connected, and the link is up.
OFF—The port is empty, or the link is down.
OK to Remove This LED displays the color BLUE. Valid options are:
ON—The controller module can be removed.
OFF—The controller module is not prepared for removal.
FRU OK This LED displays the color GREEN. Valid options are:
ON—The controller module is operating normally.
OFF—The controller module is not OK.
BLINKING—The system is booting.
Fault/Service Required This LED displays the color AM
BER. Valid options are:
ON—A fault is detected, or a service action is required.
BLINKING—A hardware-controlled power-up, cache flush, or restore error.
Ethernet LNK Status This LED displays the color GREEN. Valid options are:
ON—The Ethernet link is up.
OFF—The Ethernet port is not connected or the link is down.
Ethernet ACT Status This LED displays the color GREEN. Valid options are:
OFF—The Ethernet link has no I/O activity.
BLINKING—The Ethernet link has I/O activity.
Cache Status This LED displays the color GREEN. Valid options are:
ON—The cache is dirty, and operation is normal.
OFF—The cache is clean and contains no unwritten data.
BLINKING—A compactFlash flush or cache self-refresh is in progress,
indicating cache activity.
Expansion Port Status This LED displays the color GREEN. Valid options are:
ON—The port is connected, and the link is up.
OFF—The port is empty, or the link is down.
Table 4.2 - SA200R Controller Enclosure
Rear Panel LEDs (Continued)
LED Description
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
