HYDRAULICS
4203781 First Edition 6-9
6
Hydraulic Schematic
Continued
Figure 6-6
Weight
Transfer
Valve
Lift Valve
Left Lift Valve
Front Lift Valve
Right Lift Valve
Detent Valve
Detent Valve Detent Valve
TN2067
2
3
4
12
10
11
2
3
4
10
11
IN
0.060" Orifice
OUT
0.060" Orifice
0.060" Orifice
0.060" Orifice
Left Wing
Cylinder
Front Left
Cylinder
Front Right
Cylinder
Right Wing
Cylinder
Relief Valve
1500 psi
E
F
C
D
A
B
50 psi
300 psi 300 psi
300 psi
