Textron JACOBSEN R-311 69166 User Manual

6-10 4203781 First Edition
HYDRAULICS
6
Hydraulic Schematic
Continued
Figure 6-7
TN2068
2
3
4
10
11
Tank Check Valve
Relief Valve
3000 psi
CW Outside
Right Wing
Motor
P
Right Deck
Valve
1.04 ci
0.067
D
1.04 ci
1.04 ci
1.04 ci
1.04 ci
1.04 ci
1.04 ci
0.067
0.067
0.067
0.067
0.067
0.067
CCW Inside
Right Wing
Motor
CW Inside
Left Wing
Motor
CCW Outside
Left Wing
Motor
CCW Left
Front Motor
CW Center
Front Motor
CW Right
Front Motor
A
B
Left Deck
Valve
Front Deck
Valve
Relief Valve
3000 psi
Relief Valve
3000 psi
P
P
D
D
A
A
B
B
Solenoid
Valve
Solenoid
Valve
Solenoid
Valve
Blade Brake Relief
630 psi
Blade Brake Relief
630 psi
Blade Brake Relief
630 psi
T
T
T
D
D
D
Check
Valve
100 psi
Check
Valve
100 psi
Check
Valve
100 psi
