HYDRAULICS
4203781 First Edition 6-63
6
Disassembly, Inspection, and Assembly
See Figure 6-67.
Figure 6-67
1 Plug (3) 8 Plug (3) 15 Cap (3) 22 Spool (3)
2 O-Ring (3) 9 Plug (3) 16 Retaining Ring (3) 23 Detent Plunger (3)
3 Spring (3) 10 Plug 17 Spacer (3) 24 Detent Spring (3)
4 Poppet (3) 11 Shim (3) 18 Spring (3) 25 O-Ring (3)
5 Seat (3) 12 Spring 19 Washer (3) 26 Plug (3)
6 Plunger 13 Poppet 20 Bushing (3) 27 O-Ring (6)
7 Plunger (2) 14 Seat 21 O-Ring (6) 28 Wiper Seal (3)
TN1834
2
1
3
7
5
4
28
8
9
12
10
11
14
13
15
16
17
18
20
21
19
22
27
26
25
24
23
6
7
