Textron JACOBSEN R-311 69166 User Manual

ACCESSORIES AND MISCELLANEOUS REPAIR
4203781 First Edition 9-3
9
Component Location
See Figure 9-1.
Figure 9-1
1 OPS (Operator Protective Structure) 5 Hood 9 Right Side Fender
2 Seat and Seat Platform 6 Left Side Fender 10 Traction Pedal
3 Front Cowling 7 Rear Wheel (2) 11 Fuel Tank
4 Utility Box 8 Front Wheel (2) 12 Brake Pedal
2
8
7
11
5
12
TN2096
10
4
1
9
6
3
