9-8 4203781 First Edition
ACCESSORIES AND MISCELLANEOUS REPAIR
9
Figure 9-13
11. Support the fuel tank (9) and remove the two
mounting screws (12), lock washers (11), and flat
washers (10).
12. Remove the fuel tank from the machine.
Installation Notes
• Apply anti-seize to the fuel tank screws (12).
• Install the fuel tank by reversing the order of removal.
• Use only clean diesel fuel of the correct type (#2
diesel) from a clean, sealed container.
• If fuel was contaminated, install a new fuel filter at
this time. (See “Fuel Filter” on page 3-16.)
• Bleed fuel system.
Required Materials
Anti-Seize Compound
10
9
10
11
TN2114
11
12
12
To Next Page
