Textron JACOBSEN R-311 69166 User Manual

ACCESSORIES AND MISCELLANEOUS REPAIR
4203781 First Edition 9-9
9
Traction Pedal
Disassembly and Assembly
See Figure 9-14.
Figure 9-14
1 Forward Pedal Grip 8 Pedal Support Bracket 15 Lock Washer (2) 22 Lock Nut
2 Screw (2) 9 Flange Nut (2) 16 Switch Shim (As Required) 23 Mow Speed Stop
3 Traction Pedal 10 Nylon Bearing (2) 17 Reverse Kick-Out Switch 24 Flat Washer
4 Reverse Pedal Grip 11 Flat Washer 18 Flat Washer (2) 25 Screw
5 Carriage Bolt (2) 12 Lock Washer 19 Screw (2)
6 Flange Nut (4) 13 Pivot Screw 20 Pedal Arm
7 Tie Stud (2) 14 Nut (2) 21 Footrest Floor
1
3
2
TN2119
4
5
6
7
6
8
9
10
11
12
13
14
15
18
19
17
20
6
21
7
6
22
23
24
25
10
16
