3-20 4203781 First Edition
ENGINE
3
!
WARNING
Figure 3-35
18. Using an engine hoist, support the engine (33) and
remove the four engine mounting bolts (31) flat
washers (32), isolator washers (34), lock washers
(35), and nuts (36).
19. Check for any connected wires and components and
carefully remove the engine from the machine.
Prevent personal injury. Use a properly rated
lifting device. Always be sure the load is
balanced before lifting.
TN2097
31
32
33
34
35
36
