SPECIFICATIONS AND GENERAL INFORMATION
673831-Rev A 2-3
2
Component Location
See Figure 2-4.

CAUTION
Figure 2-4
Become familiar with operator controls, machine
components, and correct operating procedures
before beginning repair procedures.
1 Seat 5 Left Front Reel 9 Right Rear Reel 13 Hydraulic Tank
2 Instrument Panel 6 Center Reel 10 Fuel Tank 14 Battery
3 Steering Wheel 7 Right Front Reel 11 Hood
4 Traction Pedal 8 Left Rear Reel 12 ROPS
MAR0232
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
