TOHATSU MFS 25d Service Manual

6
6-9
4st 25/30 2022
Ref.
No.
Part Name Q'ty Remarks
1 Tapered Roller Bearing 30205 1
2-1 Shim 26.5-34.8-0.1 1
2-2 Shim 26.5-34.8-0.15 1
3 Bevel Gear Assy (A) 1
4 Push Rod 1
5 Ball 3/8 1
6 Spring Retainer 1
7 Snap 1
8Pin 1
9 Clutch 1
10 Spring 1
11 Propeller Shaft 1
12 Washer Bevel Gear C 18-24-1.5 1
13 Bevel Gear C 1
14 Propeller Shaft Housing Assy 1
15 O-ring 3-62.5 1
Do not reuse.
16 Ball Bearing 6205 1
Do not reuse.
17 Roller Bearing 18-25-2.5 1
Do not reuse.
18 Oil Seal 18-28-8 2
Do not reuse.
19-1 Propeller Assy (8) 1
19-2 Propeller Assy (9) 1
19-3 Propeller Assy (10) 1
19-4 Propeller Assy (11) 1
19-5 Propeller Assy (12) 1
19-6 Propeller Assy (13) 1
19-7 Propeller Assy (14) 1
20 Bolt 2
21 Washer 2
22 Propeller Hardware Kit 1
23 Thrust Holder 1
24 Washer 12.5-32-2.5 1
25 Propeller Nut 1
26 Split Pin 3-22 1
Do not reuse.
