TOHATSU MFS 25d Service Manual

7-5
4st 25/30 2022
7
Ref.
No.
Part Name Q'ty Remarks
1-1 Drive Shaft Housing Assy (S) 1
1-2 Drive Shaft Housing Assy (S) 1
1-3 Drive Shaft Housing Assy (L) 1
1-4 Drive Shaft Housing Assy (L) 1
2 Oil Seal 1
Do not reuse.
3 Dowel Pin 6-16 2
4 Drain Bolt 1
5 Washer 1
Do not reuse.
6 Flushing Connector Cap 1
7 Seal Ring 1
8 Engine Basement Seal 1
9 Bolt 1
10 Grommet 1
11 Sub-Water Inlet Hose Plug 1
12 Bolt 8-P1.25 6
13 Idle Exhaust Port Gasket 2
Do not reuse.
14 Idle Exhaust Plate 1
15 Idle Exhaust Port Cover 1
16 Nipple 1
17 Apron Stay 1
18 Bolt 7
19 Grommet 1
20 Bolt 2
21 Shoulder Bolt 1
22 Apron 1
23 Screw 4
24 Extension Housing 1
25 Bolt 1
26 Nut 1
27 Bolt 4
28 Washer 8.1-16-1.5 4
29 Storage Decal 1
