TOHATSU MFS 25d Service Manual

7-7
4st 25/30 2022
7
Ref.
No.
Part Name Q'ty Remarks
1 Clamp Bracket (R) 1
2 Clamp Bracket (L) 1
3 Anode 1
4 Bolt 1
5 Co-Pilot Decal 1
6 Swivel Bracket Shaft Assy 1
7 Cap Nut 2
8 Bushing 2
9 Nylon Nut 7/8-14 1
10 Distance Piece 1
11 Nut 2
12 Washer 4
13 Thrust Rod 1
14 Thrust Rod Spring 1
15 Swivel Bracket Assy 1
16 Grease Fitting 3
17 Nylon Nut 8-P1.25 1
18 Washer 1
19 Friction Lever 1
20 Washer 8.1-20-0.8 1
21 Bolt 1
22 Disc 2
23 Bolt 2
24 Plate 1
25 Friction Lever Bracket 1
26 Steering Shaft Assy 1
27 Rubber Mount (Lower) 1
28 Mount Bracket 1
29 Bolt 4
30 Damper (Lower) 1
31 Bolt 4
32 Washer 13-34-3 2
33 Damper 21-36-5 2
34 Washer 4
35 Nylon Nut 10-P1,25 4
36 Anode 1
37 Bolt 1
38 Bolt Cover 2
39 Bolt 2
40 Thrust Plate (Upper) 21-50-2 1
41 Bushing 30-36-41 2
42 O-ring 3.5-29.7 1
Do not reuse.
43 Thrust Plate (Lower) 1
44 Damper (Upper) 2
45 Rubber Mount (Upper) 2
