TOHATSU MFS 25d Service Manual

7-9
4st 25/30 2022
7
Ref.
No.
Part Name Q'ty Remarks
46 Bolt 4
47 Damper (Upper) 1
48 Carrying Handle 1
49 Tilt Stopper 1
50 Spring Pin 1
51 Bushing 10.2-12-29.5 1
52 Setting Plate 1
53 Bolt 2
54 Setting Piece 1
55 Friction Spring 1
56 Anode 1
57 Bolt 1
58 Reverse Lock Arm 1
59 Reverse Lock Rod 1
60 Split Pin 2-12 1
61 Reverse Lock 2
62 Shoulder Bolt 2
63 Reverse Lock Spring (L) 2
64 Washer 6-16-1.5 2
65 Reverse Lock Lever 1
66 Reverse Lock Link 1
67 Reverse Lock Lever Spring 1
68 Shoulder Bolt 6-8 1
69 Washer 1
70 Bushing 8.1-20 1
71 Washer 8.5-18-1.6 1
72 Washer 6-16-1.5 1
73 Clamp Screw Kit 2
74 Clamp Screw Assy 1
75 Clamp Screw 1
76 Clamp Screw Handle 1
77 Spring Pin 1
78 Clamp Screw Pad 1
79 E-Ring d=5 1
Do not reuse.
80 Rigging Bolt Set 1
81 Bolt 2
82 Washer 4
83 Nylon Nut 8-P1.25 2
