TOHATSU MFS 25d Service Manual

7-11
4st 25/30 2022
7
Ref.
No.
Part Name Q'ty Remarks
1 Clamp Bracket (PTT-R) 1
2 Clamp Bracket (PTT-L) 1
3 Swivel Bracket Shaft Assy 1
4 Bushing 2
5 PTT Thrust Rod 1
6 Snap Pin 1
7 Swivel Bracket Assy 1
8 Collar 10.2-12-12 2
9 Tilt Stopper Spring 1
10-1 Tilt Stopper Kit 1 For PT model
10-2 Tilt Stopper Kit 1 For Gas assist model
11 Tilt Stopper Grip 1
12 Spring Pin 3.5-16 1
Do not reuse.
13 PT Assy 1
14 Cylinder Pin (Upper) 1
15 Bolt 1
16 Washer 6.5-23-1.5 1
17 Bushing 13-16-40 1
18 Bushing 13-17-19.5 1
19 Bushing 1
20 Bushing 18-24-22 5
21 Cylinder Pin (Lower) 1
22 Washer 18.2-34-1 2
23 C-ring d=18 2
24 Gas Shock Absorber 1
25 Collar 1
26 Reverse Lock Lever 1
27 Bolt 6-35 1
28 Washer 2
29 Nut 1
30 Anode 1
31 Bolt 1
32 Anode 2
33 Bolt 2
34 Clamp 6.5-14L 1
35 Screw 1
36 Clamp Screw Kit 2
37 Clamp Screw (PTT) 1
38 Clamp Screw Pad 1
39 E-ring d=5 1
Do not reuse.
40 Rigging Bolt Set 1
41 Bolt 12-105 P1.25 4
42 Washer 13-34-3 4
43 Washer 4
44 Nylon Nut 12-P1.25 4
45 Band Lead Wire 300 1
Do not reuse.
