TOHATSU MFS 25d Service Manual

7-13
4st 25/30 2022
7
Ref.
No.
Part Name Q'ty Remarks
1 Manual Valve Assy 1
2 Seal Set 1
3 O-ring 2.4-9.8 1
Do not reuse.
4 C-ring 1
Do not reuse.
5 Joint 1
6 Nut 1
7 Dust Seal 1
8 O-ring 2.4-12.3 1
Do not reuse.
9 Cylinder 1
10 Inner Tube 1
11 Piston Rod Assy 1
12 O-ring 2-28.5 1
Do not reuse.
13 Free Piston 1
14 Back-Up Ring 1
15 O-ring 2.4-27.7 1
Do not reuse.
16 O-ring 2-43.5 1
Do not reuse.
17 O-ring 2-34.5 1
Do not reuse.
18 Seal Washer 1
19 Valve Seat 1
20 O-ring 1.5-6.5 1
Do not reuse.
21 Ball 1
22 Spring Seat 1
23 Spring 1
24 O-ring 1.5-6.5 2
Do not reuse.
25 Pump 1
26 Bolt 3
27 Coupling 1
28 Motor Assy 1
29 O-ring 2-62.5 1
Do not reuse.
30 O-ring 2.4-66.6 1
Do not reuse.
31 Reserve Tank 1
32 Bolt 2
33 Cap 1
34 O-ring 1.9-9.8 1
Do not reuse.
