TOHATSU MFS 25d Service Manual

7-23
4st 25/30 2022
7
Ref.
No.
Part Name Q'ty Remarks
1 Bottom Cowl 1
2 Mount 8.5-14-2.5 8
3 Spacer 6.2-9-15.7 4
4 Bolt 4
5 Washer 6.5-21-1 4
6 Nipple 1
7 Pilot Lamp Assy 1
8 Gasket 1
9 PTT Switch Assy Bracket 1
10 Bolt 2
11 Grommet 1
12 PTT Switch Assy 1
13 Remote Cont Cable Stay Cover 1
14 Bolt 2
15 Cowl Latch Assy 1
16 Bolt 1
17 Washer 6.5-23-1.5 1
18 Grommet 1
19 Grommet 40-18-3 1
20 Cable Terminal Holder Cover 1
21 Hook 3
22 Grommet 13.2 3
23 Grommet 1
24 Grommet 1
25 Grommet 22-3 1
26 Fuel Connector (Male) 1
27 Bolt 1
28 Bolt 1
29 Nut 1
30 Fuel Connector Protector 1
31 Grommet 1
32 Grommet 1
33 Cable Clip 1
34 Bolt 1
35 Drain Plug (Engine Basement) 2
36 Warning Decal 1
37 Seal 2
