7-25
4st 25/30 2022
7
Ref.
No.
Part Name Q'ty Remarks
1 Shift Lever Shaft Assy 1
2 Neutral Switch 1
3 Neutral Switch Actuator 1
4 Neutral Switch Bracket 1
5 Bolt 2
6 Holder 1
7 Bolt 2
8 Holder 1
9 Bolt 2
10 Shift Detent Spring 2
11 Shift Detent Supporter 1
12 Bolt 1
13 Throttle Drum Assy 1
14 Bolt 1
15 Washer 6-16-1.5 2
16 Collar 6.5-10.5-9.3 1
17 Throttle Wire Bracket 1
18 Bolt 2
19 Link Rod Assy (Throttle) 1
20 Snap Pin d=6 1
21 Shift Rod 1
22 Grommet 17-3 1
23 Shift Rod Joint 1
24 Spring Pin 3-12 1
Do not reuse.
25 Shift Rod Joint Retainer 1
To Next Page
