*1: Angle from the vertical position when the transom angle is at 12°
Item Type Unit
MF/EF (Manual Tilt Model) EFG (Gas Assist Model) EFT (Power Tilt Model)
mm in mm in mm in
A mm/in 571 22.50 571 22.50 571 22.50
B mm/in 338 13.30 338 13.30 338 13.30
C deg. 38
D
S mm/in 763 30.05 768 30.25 777 30.60
L mm/in 873 34.35 873 34.35 889 35.00
UL mm/in 983 38.70 978 38.50 1001 39.40
E mm/in 578 22.75 555 21.85 555 21.85
F mm/in 535 21.05 558 21.95 558 21.95
G mm/in 406 15.80 381 14.80 401 15.65
H mm/in 204 8.05 182 7.15 182 7.15
I
S mm/in 425 16.75 425 16.75 425 16.75
L mm/in 552 21.75 552 21.75 552 21.75
UL mm/in 679 26.75 679 26.75 679 26.75
J
S mm/in 721 28.40 721 28.40 721 28.40
L mm/in 848 33.40 848 33.40 848 33.40
UL mm/in 975 38.40 975 38.40 975 38.40
K mm/in 40-60 1.55-2.35 40-60 1.55-2.35 40-60 1.55-2.35
L deg. 12
M mm/in 408 16.05 431 16.95 431 16.95
N deg. 60 56 62
O mm/in 147 5.80 147 5.80 147 5.80
P mm/in 686 27.00 703 27.65 706 27.80
Q mm/in 495 19.50 495 19.50 495 19.50
R mm/in 401 15.80 401 15.80 401 15.80
Trim Angle
(Position)
deg. *1
-9 to 16
(6)
-4 to 8
(4)
