TOHATSU MFS 25d Service Manual

8
8-17
4st 25/30 2022
Ref.
No.
Parts Name Q'ty Remarks
1 Vapor Separator Assy 1
2 Cover 1
3 Seal 1
4 Screw 4
5 Drain Screw 1
6 Gasket 1
Do not reuse.
7 Float Valve Assy 1
8 Float Arm Pin 1
9 Float 1
10 Grommet 1
11 Filter (Inlet) 1
12 Holder 1
13 Fuel Feed Pump 1
14 O-ring 1
Do not reuse.
15 O-ring 1
Do not reuse.
16 O-ring 1
Do not reuse.
17 Fuel Regulator 1
18 Screw 1
19 VST Connector 1
20 Clip 1
21 Screw 4
22 Washer 6-16-1.5 2
23 Rubber Mount 2
24 Collar 2
25 Bolt 2
26 Plate 1
27 Fuel Filter Assy 1
28 Cup 1
29 Filter 1
30 O-ring 1
Do not reuse.
31 O-ring 1
Do not reuse.
32 Drain Valve 1
33 Seal 1
Do not reuse.
34 Float 1
35 Bolt 1
36 Fuel Filter Holder 1
37 Fuel Pump Assy 1
38 O-ring 3.5-25.7 1
Do not reuse.
39 Bolt 2
40-1 Fuel Hose 1
40-2 Fuel Hose W/Protector 1
