*1: Angle from the vertical position when the transom angle is at 12°
Item Type Unit
EP (Manual Tilt Model) EPT (Power Tilt Model)
mm in mm in
A mm/in 338 13.30 338 13.30
B mm/in 338 13.30 338 13.30
C deg. 38
D
S mm/in 763 30.05 777 30.60
L mm/in 873 34.35 889 35.00
UL mm/in 983 38.70 1001 39.40
E mm/in 406 15.80 401 15.60
F mm/in 535 21.05 559 22.00
G mm/in 197 7.75 173 6.80
H mm/in 75 2.95 51 2.00
I
S mm/in 425 16.75 425 16.75
L mm/in 552 21.75 552 21.75
UL mm/in 679 26.75 679 26.75
J
S mm/in 721 28.40 721 28.40
L mm/in 848 33.40 848 33.40
UL mm/in 975 38.40 975 38.40
K mm/in 40-60 1.55-2.35 40-60 1.55-2.35
L deg. 12
M mm/in 408 16.05 432 17.00
N deg. 60 62
O mm/in 147 5.80 147 5.80
P mm/in 686 27.00 705 27.75
Q mm/in 495 19.50 495 19.50
R mm/in 389 15.30 389 15.30
Trim Angle
(Position)
deg. *1
-9 to 16
(6)
-4 to 8
(4)
