4. SYSTEM MODE (For Service Persons and System Administrators) EO13-33005
4.2 Diagnostic Test
4- 12
Item Description Value
BASIC BASIC interpreter OFF: BASIC interpreter function is
disabled.
ON: BASIC interpreter function is
enabled.
BASIC TRACE BASIC trace OFF: BASIC trace function is disabled.
ON: BASIC trace function is enabled.
SHELL Shell function OFF: Shell function is disabled.
ON: Shell function is enabled.
Item Description Value
<<IrDA Setting>
IrDA MODE IrDA mode IrCOMM
TEC
OFF
BAUD RATE Maximum IrDA baud rate 9600 (bps)
19200 (bps)
38400 (bps)
57600 (bps)
115200 (bps)
Item Description Value
<<USB Setting>
Enable/disable of USB serial
number
DISABLE
ENABLE
SERIAL NUMBER
USB serial number 8S01FA590001
* USB serial number differs depending on the date of setting and a PC used
for setting at the factory.
Item Description Value
<<RS-232C Setting> * When the RS-232C module is installed.
BAUD RATE RS-232C baud rate 9600 (bps)
19200 (bps)
38400 (bps)
57600 (bps)
115200 (bps)
PARITY RS-232C Parity EVEN
NONE
Item Description Value
<<Bluetooth Setting> * When the Bluetooth module is installed.
DEVICE NICKNAME Bluetooth device nickname
ADDRESS Bluetooth device address Fixed module address
INQUIRY Inquiry scan time OFF
60sec.
EVERY
SCAN INTERVAL Inquiry/page scan interval 18 to 4096
SCAN WINDOW Inquiry/page scan window 18 to 4096
SECURITY LEVEL Security level OFF
LINK
To Next Page
