Toshiba Strata DK40 - Programs 46-11~41 Toll Restriction Class (1~4) Parameters

Programs 46-11~41 Toll Restriction Class (1~4) Parameters Toll Restriction
Strata DK40 Programming Manual Spring 1999
4-15
Programs 46-11~41
Toll Restriction Class (1~4) Parameters
Program Type:
Toll Restriction
Initialised Default:
Leaves all LED’s OFF
Programs 46-11 ~ 41 Overview
This program allows the Exception tables to be defined for each Class. To enter the codes into
the Exception Tables see Program 47.
There are up to 8 Toll Restriction Exception tables available on the system. Each table may
hold one number of up to 7 digits long. More than one Exception table may be assigned for
each class. Program 46-11 assigns Exception tables to Class 1; Program 46-21 assigns
Exception tables to Class 2; Program 46-31 assigns Exception tables to Class 3; etc.
Programs 46-11 ~ 41. These programs should be run for the Exception table assignments for
each class of Toll Restriction.
◆ LEDs 01 ~ 08: Exception Tables 1 ~ 08-Select the exception tables that apply to the
class being defined by marking an X in the box.
Note
Each class can be assigned any or all of the available Exception tables.
(QWHU 3URJ 0RGH 0 6SNU 79+ROG 0 6SNU 4 +ROG 0 6SNU & & +ROG 0 6SNU & & +ROG
Processor Toll Restriction Class Exception Tables
DK40 1~4 8
LED X LED ON LED OFF
20~09
Not Used
08
Table 08 INT/STD/Local Exception Not Selected
07
Table 07 INT/STD/Local Exception Not Selected
06
Table 06 INT/STD/Local Exception Not Selected
05
Table 05 INT/STD/Local Exception Not Selected
04
Table 04 INT/STD/Local Exception Not Selected
03
Table 03 INT/STD/Local Exception Not Selected
02
Table 02 INT/STD/Local Exception Not Selected
01
Table 01 INT/STD/Local Exception Not Selected
Light LED Buttons as required to assign Table to Class.
Select Class from Legend below.
