Program 01 Station Logical Port Display and/or Change
System & Station
Strata DK40 Programming Manual Spring 1999
3-1
System & Station
3
Program 01
Station Logical Port Display and/or Change
Program Type:
Station
Initialised Default:
Logical port number = physical port number
Program 90, 91-1, or 91-9 initialises Program 01
Program 01 Overview
Program 01 enables you to enter a physical port to display the associated logical port. You
then have the option to assign a new logical port to the physical port. (To return ports to their
initialised settings, see Programs 90 and 91-1.)
Note
Record port locations on Program 04 record sheet.
(QWHU 3URJ 0RGH 0 6SNU 34+ROG 0 6SNU +ROG 0 6SNU & & +ROG 0 6SNU & & +ROG
Processor [PDN] Port Range
DK40 000~027
To Save existing Logical Port
6SNU
SELECT = Physical Port Number
The logical port number associated with the physical
port displays after the physical port number is entered.
Enter new Logical Port
to change existing Logical Port
To Next Page
