Encompass 4 Reader System Guide
D-10
526 Display I/O status IOST Cx Ox Ix Dx
C0 = host controls outputs
C1 = predefined output mode
O0 = both outputs off
O1 = output0 on
O2 = output1 on
O3 = both outputs on
I0 = both inputs false
I1 = input0 true
I2 = input1 true
I3 = both inputs true
D0 to DF = output pulse duration
where
D0 = 4 ms
D1 = 8 ms
D2 = 12 ms
D3 = 16 ms
D4 = 20 ms
D5 = 24 ms
D6 = 32 ms
D7 = 40 ms
D8 = 48 ms
D9 = 60 ms
DA = 76 ms
DB = 152 ms
DC = 228 ms
DD = 300 ms
DE = 376 ms
DF = 752 ms
Table D-2 Encompass 4 Reader Commands Listed Numerically (continued)
Number Command Name Reader Message
