Command Quick Reference
D-21
I/O status display 526 IOST Cx Ox Ix Dx
C0 = host controls outputs
C1 = predefined output mode
O0 = both outputs off
O1 = output0 on
O2 = output1 on
O3 = both outputs on
I0 = both inputs false
I1 = input0 true
I2 = input1 true
I3 = both inputs true
D0 - DF = output pulse duration
where
D0 = 4 ms
D1 = 8 ms
D2 = 12 ms
D3 = 16 ms
D4 = 20 ms
D5 = 24 ms
D6 = 32 ms
D7 = 40 ms
D8 = 48 ms
D9 = 60 ms
DA = 76 ms
DB = 152 ms
DC = 228 ms
DD = 300 ms
DE = 376 ms
DF = 752 ms
IAG disable 486 Done
IAG enable 487 Done if Encompass 4 Reader
model supports this tag protocol.
Error if tag protocol is
unsupported.
IAG RF attenuation set
XX = 00 to 0F
646XX Done
Input inversion disable 6940 Done
Input inversion enable 6941 Done
Input status change display 560 SSTC Ex Mx
E0 = status change reports
disabled
E1 = status change reports
enabled
M0 = no reporting
M1 = report change on input0
M2 = report change on input1
M3 = report change on either
input
