Encompass 4 Reader System Guide
D-24
Set RF attenuation to 0 dB (full
power)
64400 Done
RF off on timeout 6920 Done
RF off on timeout/no presence 6922 Done
RF off on timeout/tag 6921 Done
RF turn off 6400 Done
RF turn on 6401 Done
RF on by input control 641 Done
RF operating frequency from 860
to 930 in 250 kHz steps select
XXX = 000 to 118 (hexadecimal)
647XXX Done
RF operating frequency select 642NN Done
RF status display 527 RFST Cx Ox Tx Fxxx Rxx Gxx
Axx Ixx
C0 = RF controlled by host
C1 = RF-by-presence sensor
O0 = RF off
O1 = RF on
T1 = uniqueness timeout of 2
min
T2 = uniqueness timeout of 15
sec
T3 = uniqueness timeout of 30
sec
Fxxx = RF output frequency,
xxx = 000 to 118
Rxx = Tag decoder range
(distance) for ATA tags, 00 to 1F
hexadecimal range value
Gxx = Tag decoder range
(distance) for eGo Plus Tags, 00
to 1F hexadecimal range value
Axx = RF power attenuation, 00
max to 0A min (10 dB less than
max)
Ixx = IAG RF power attenuation,
00 max to 0F min (15 dB less
than max)
If you enter RF settings using
command #642NN, the display
command for RF output
frequency, F is "Fxx" and
indicates use of the backward-
compatible frequency entry
method.
Table D-3 Encompass 4 Reader Commands Listed Alphabetically (continued)
Command Name Code Reader Message
