Vacon 100 flow Applications Manual

4.1.4 I/O
Table 17: I/O signal monitoring
Index Monitoring value Unit Scale ID Description
V2.4.1 Slot A DIN 1, 2, 3 1 15
V2.4.2 Slot A DIN 4, 5, 6 1 16
V2.4.3 Slot B RO 1, 2, 3 1 17
V2.4.4 Analogue input 1 % 0.01 59 Slot A.1 as default.
V2.4.5 Analogue input 2 % 0.01 60 Slot A.2 as default.
V2.4.6 Analogue input 3 % 0.01 61 Slot D.1 as default.
V2.4.7 Analogue input 4 % 0.01 62 Slot D.2 as default.
V2.4.8 Analogue input 5 % 0.01 75 Slot E.1 as default.
V2.4.9 Analogue input 6 % 0.01 76 Slot E.2 as default.
V2.4.10 Slot A AO1 % 0.01 81
4.1.5 TEMPERATURE INPUTS
NOTE!
This parameter group is visible when you have an option board for temperature
measurement (OPT-BH).
Table 18: Monitoring the temperature inputs
Index Monitoring value Unit Scale ID Description
V2.5.1
Temperature
input 1
°C 0.1 50
V2.5.2
Temperature
input 2
°C 0.1 51
V2.5.3
Temperature
input 3
°C 0.1 52
V2.5.4
Temperature
input 4
°C 0.1 69
V2.5.5
Temperature
input 5
°C 0.1 70
V2.5.6
Temperature
input 6
°C 0.1 71
MONITORING MENU VACON · 119
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
4

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
