Vacon 100 flow Applications Manual

Table 84: Multi-setpoint parameters
Index Parameter Min Max Unit Default ID Description
P3.13.12.19
Multi-Setpoint
Selection 2
DigIN
Slot0.1
15578
P3.13.12.20
Multi-Setpoint
Selection 3
DigIN
Slot0.1
15579
5.14 GROUP 3.14: EXTERNAL PID CONTROLLER
Table 85: Basic settings for the external PID controller
Index Parameter Min Max Unit Default ID Description
P3.14.1.1 Enable External PID 0 1 0 1630
0 = Disabled
1 = Enabled
P3.14.1.2 Start Signal
DigIN
Slot0.2
1049
OPEN = PID2 in stop
mode
CLOSED = PID2 regu-
lating
P3.14.1.3 Output in Stop 0.0 100.0 % 0.0 1100
P3.14.1.4 PID Gain 0.00 1000.00 % 100.00 1631 See P3.13.1.1
P3.14.1.5 PID Integration Time 0.00 600.00 s 1.00 1632 See P3.13.1.2
P3.14.1.6 PID Derivation Time 0.00 100.00 s 0.00 1633 See P3.13.1.3
P3.14.1.7
Process Unit Selec-
tion
0 46 0 1635
See P3.13.1.4
P3.14.1.8 Process Unit Min Varies Varies Varies 0 1664 See P3.13.1.5
P3.14.1.9 Process Unit Max Varies Varies Varies 100 1665 See P3.13.1.6
P3.14.1.10
Process Unit Deci-
mals
0 4 2 1666
See P3.13.1.7
P3.14.1.11 Error Inversion 0 1 0 1636 See P3.13.1.8
P3.14.1.12 Dead Band 0.00 Varies Varies 0.0 1637 See P3.13.1.9
P3.14.1.13 Dead Band Delay 0.00 320.00 s 0.00 1638 See P3.13.1.10
VACON · 174 PARAMETERS MENU
5
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
