Vacon 100 flow Applications Manual

5.6 GROUP 3.6: FIELDBUS DATA MAPPING
Table 52: Fieldbus data mapping
Index Parameter Min Max Unit Default ID Description
P3.6.1
Fieldbus Data Out 1
Selection
0 35000 1 852
P3.6.2
Fieldbus Data Out 2
Selection
0 35000 2 853
P3.6.3
Fieldbus Data Out 3
Selection
0 35000 3 854
P3.6.4
Fieldbus Data Out 4
Selection
0 35000 4 855
P3.6.5
Fieldbus Data Out 5
Selection
0 35000 5 856
P3.6.6
Fieldbus Data Out 6
Selection
0 35000 6 857
P3.6.7
Fieldbus Data Out 7
Selection
0 35000 7 858
P3.6.8
Fieldbus Data Out 8
Selection
0 35000 37 859
Table 53: The default values for Process Data Out in fieldbus
Data Default value Scale
Process Data Out 1 Output frequency 0.01 Hz
Process Data Out 2 Motor speed 1 rpm
Process Data Out 3 Motor current 0.1 A
Process Data Out 4 Motor torque 0.1%
Process Data Out 5 Motor power 0.1%
Process Data Out 6 Motor voltage 0.1 V
Process Data Out 7 DC link voltage 1 V
Process Data Out 8 Last active fault code 1
For example, the value 2500 for Output frequency equals 25.00 Hz, because the scale is 0.01.
All the monitoring values that you can find in Chapter 4.1 Monitor group are given the scale
value.
PARAMETERS MENU VACON · 149
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
5

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
