V2.4.6 ANALOG INPUT 3 (ID 61)
This monitoring value shows the value of the analogue input signal as a percentage of the
used range.
V2.4.7 ANALOG INPUT 4 (ID 62)
This monitoring value shows the value of the analogue input signal as a percentage of the
used range.
V2.4.8 ANALOG INPUT 5 (ID 75)
This monitoring value shows the value of the analogue input signal as a percentage of the
used range.
V2.4.9 ANALOG INPUT 6 (ID 76)
This monitoring value shows the value of the analogue input signal as a percentage of the
used range.
V2.4.10 SLOTA AO 1 (ID 81)
This monitoring value shows the value of the analogue output as a percentage of the used
range.
9.3 TEMPERATURE INPUTS
The monitoring values related to temperature input settings are only available if a B8 or BH
option board is installed.
V2.5.1 TEMPERATURE INPUT 1 (ID 50)
This monitoring value shows the measured value of the temperature.
The unit of the monitoring value is celsius degrees or fahrenheit degrees, depending on the
'C/F Selection' parameter value.
NOTE!
The list of temperature inputs is made of the first 6 available temperature inputs.
The list starts from slot A and ends in slot E. If an input is available but no sensor is
connected, the list shows the maximum value because the measured resistance is
endless. To make the value go to its minimum value, hardwire the input.
V2.5.2 TEMPERATURE INPUT 2 (ID 51)
This monitoring value shows the measured value of the temperature.
The unit of the monitoring value is celsius degrees or fahrenheit degrees, depending on the
'C/F Selection' parameter value.
V2.5.3 TEMPERATURE INPUT 3 (ID 52)
This monitoring value shows the measured value of the temperature.
MONITORING VALUE DESCRIPTIONS VACON · 205
