Vacon 100 flow Applications Manual

Table 102: Frost protection parameters
Index Parameter Min Max Unit Default ID Description
P3.21.5.5
Frost Protection
Temperature Limit
P3.21.5.
3
P3.21.5.4 °C/°F 5.00 (°C) 1708
P3.21.5.6
Frost Protection Fre-
quency
0.0 P3.3.1.2 Hz 10.0 1710
V3.21.5.7
Frost Temperature
Monitoring
Varies Varies °C/°F 1711
This monitoring value
shows the value of the
temperature signal
that is used for Frost
Protection function.
Table 103: Flow switch parameters
Index Parameter Min Max Unit Default ID Description
P3.21.6.1 Flow Switch
DigIN
Slot0.2
15590
P3.21.6.2
Flow Switch Fault
Delay
0.0 3000.0 s 20.0 15585
P3.21.6.3
Flow Switch Bypass
at Start
0.0 3000.0 s 20.0 15586
P3.21.6.4
Flow Switch Mini-
mum Frequency
Varies Varies Hz 0.0 15587
5.21 GROUP 3.23: ADVANCED HARMONIC FILTER
Table 104: Advanced harmonic filter parameters
Index Parameter Min Max Unit Default ID Description
P3.23.1 Cap Disconnect Limit 0 100 % 0 15510
P3.23.2 Cap Disconnect Hyst 0 100 % 0 15511
P3.23.3
AHF Over Tempera-
ture
DigIN
Slot0.1
15513
P3.23.4 AHF Fault Response 0 3 2 15512
0 = No Action
1 = Alarm
2 = Fault
3 = Fault, Coast
VACON · 186 PARAMETERS MENU
5
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
