Vacon 100 flow Applications Manual

5.15 GROUP 3.15: MULTI-PUMP
Table 89: Multi-pump parameters
Index Parameter Min Max Unit Default ID Description
P3.15.1 Multi-pump Mode 0 2 0 * 1785
0 = Single Drive
1 = Multifollower
2 = Multimaster
P3.15.2 Number of Pumps 1 8 1 * 1001
P3.15.3 Pump ID Number 1 8 0 1500
P3.15.4
Start and Feedback
Signals
0 2 1 1782
0 = Not Connected
1 = Only Start Signal
Connected
2 = Both Signals Con-
nected
P3.15.5 Pump Interlocking 0 1 1 * 1032
0 = Not used
1 = Enabled
P3.15.6 Autochange 0 2 1 * 1027
0 = Disabled
1 = Enabled (interval)
2 = Enabled (weekdays)
P3.15.7 Autochanged Pumps 0 1 1 * 1028
0 = Auxiliary pumps
1 = All pumps
P3.15.8 Autochange Interval 0.0 3000.0 h 48.0 * 1029
P3.15.9 Autochange Days 0 127 0 1786
B0 = Sunday
B1 = Monday
B2 = Tuesday
B3 = Wednesday
B4 = Thursday
B5 = Friday
B6 = Saturday
P3.15.10
Autochange: Time of
Day
00:00:00 23:59:59 Time 00:00:00 1787
P3.15.11
Autochange: Fre-
quency Limit
0.00 P3.3.1.2 Hz 25.00 * 1031
P3.15.12
Autochange: Pump
Limit
0 8 1 * 1030
P3.15.13 Bandwidth 0 100 % 10 * 1097
Setpoint = 5 bar
Bandwidth = 10%.
P3.15.14 Bandwidth Delay 0 3600 s 10 * 1098
P3.15.15
Constant Production
Speed
0.0 100.0 % 80.0 * 1513
PARAMETERS MENU VACON · 177
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
5

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
