1
Language selection (P6.1) The selection is different in all the language
packages
2
Daylight saving* (P5.5.5)
Russia
US
EU
OFF
3 Time* (P5.5.2) hh:mm:ss
4 Year* (P5.5.4) yyyy
5 Date* (P5.5.3) dd.mm.
* If a battery is installed, you see these steps
6
Run Startup Wizard?
Yes
No
Select Yes and push the OK button. If you select No, the AC drive moves away from the
Startup wizard.
To set the parameter values manually, select No and push the OK button.
7
Select the application (P1.2 Application, ID212)
Standard
HVAC
PID control
Multi-pump (single drive)
Multi-pump (multidrive)
To continue to the wizard of the application you selected in step 7, select Yes and push the OK
button. See the description of the application wizards in 2 Wizards.
If you select No and push the OK button, the Startup wizard stops and you must select all the
parameter values manually.
To start the Startup wizard again, you have 2 alternatives. Go to the parameter P6.5.1
Restore Factory Defaults or to the parameter B1.1.2 Startup Wizard. Then set the value to
Activate.
1.4 DESCRIPTION OF THE APPLICATIONS
Use the parameter P1.2 (Application) to make a selection of an application for the drive.
Immediately when the parameter P1.2 changes, a group of parameters get their preset
values.
1.4.1 STANDARD AND HVAC APPLICATIONS
Use the Standard and HVAC applications to control pumps or fans, for example.
It is possible to control the drive from the Keypad, Fieldbus or I/O terminal.
VACON · 14 QUICK STARTUP GUIDE
1
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
