Vacon 100 flow Applications Manual

NOTE!
The values are visible as checkboxes on the graphical display. If a box is selected,
the limit controller is active.
V2.6.14 MOTOR SHAFT POWER 1 DECIMAL (ID 98)
This monitoring value shows the actual shaft power of the motor (calculated value with one
decimal). The unit of measurement is kW or hp, depending on the 'kW/hp Selection'
parameter value.
9.5 TIMER FUNCTIONS
V2.7.1 TC 1, TC 2, TC 3 (ID 1441)
This monitoring value shows the status of the time channels 1, 2 and 3.
V2.7.2 INTERVAL 1 (ID 1442)
This monitoring value shows the status of the interval function.
V2.7.3 INTERVAL 2 (ID 1443)
This monitoring value shows the status of the interval function.
V2.7.4 INTERVAL 3 (ID 1444)
This monitoring value shows the status of the interval function.
V2.7.5 INTERVAL 4 (ID 1445)
This monitoring value shows the status of the interval function.
V2.7.6 INTERVAL 5 (ID 1446)
This monitoring value shows the status of the interval function.
V2.7.7 TIMER 1 (ID 1447)
The monitoring value shows the remaining time on the timer if the timer is active.
V2.7.8 TIMER 2 (ID 1448)
The monitoring value shows the remaining time on the timer if the timer is active.
V2.7.9 TIMER 3 (ID 1449)
The monitoring value shows the remaining time on the timer if the timer is active.
V2.7.10 REAL TIME CLOCK (ID 1450)
This monitoring value shows the actual time of the real time clock in a format of hh:mm:ss.
VACON · 208 MONITORING VALUE DESCRIPTIONS
9
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
