Vacon 100 flow Applications Manual

Table 19: Monitoring of the advanced values
Index Monitoring value Unit Scale ID Description
V2.6.7
Motor Current 1
Decimal
0.1 45
V2.6.8
Frequency Refer-
ence Source
1 1495
0 = PC
1 = Preset Freqs
2 = Keypad Reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID Controller
8 = Motor Potentiom.
10 = Flushing
11 = Block Out.1
12 = Block Out.2
13 = Block Out.3
14 = Block Out.4
15 = Block Out.5
16 = Block Out.6
17 = Block Out.7
18 = Block Out.8
19 = Block Out.9
20 = Block Out.10
100 = Not defined
101 = Alarm,PresetFreq
102 = Autocleaning
V2.6.9
Last Active Fault
Code
1 37
V2.6.10
Last Active Fault
ID
1 95
V2.6.11
Last Active Alarm
Code
1 74
V2.6.12
Last Active Alarm
ID
1 94
V2.6.13
Motor Regulator
Status
1 77
B0 = Current Limit (Motor)
B1 = Current Limit (Generator)
B2 = Torque Limit (Motor)
B3 = Torque Limit (Generator)
B4 = Overvoltage Control
B5 = Undervoltage Control
B6 = Power Limit (Motor)
B7 = Power Limit (Generator)
V2.6.14
Motor Shaft Power
1 Deceleration
kW/hp 98
4.1.7 TIMER FUNCTIONS MONITORING
Monitor the values of Timer functions and the Real Time Clock.
MONITORING MENU VACON · 121
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
4

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
