Table 3: M1 Quick Setup
Index Parameter Min Max Unit Default ID Description
1.29 RO3 Function 0 74 1 11007 See P3.5.3.2.1
1.30 AO1 Function 0 31 2 10050 See P3.5.4.1.1
Table 4: M1.31 Standard / M1.32 HVAC
Index Parameter Min Max Unit Default ID Description
1.31.1 Preset Frequency 1 P1.3 P1.4 Hz 10.0 105
Make the selection of a
preset frequency with
the digital input DI4.
1.31.2 Preset Frequency 2 P1.3 P1.4 Hz 15.0 106
Make the selection of a
preset frequency with
the digital input DI5.
1.31.3 Preset Frequency 3 P1.3 P1.4 Hz 20.0 126
Make the selection of a
preset frequency with
the digital input DI4
and DI5.
1.4.2 PID CONTROL APPLICATION
You can use the PID control application with processes where you control the process
variable, for example pressure, through the control of the speed of the motor.
In this application, the internal PID controller of the drive is configured for 1 setpoint and 1
feedback signal.
You can use 2 control places. Make the selection of the control place A or B with DI6. When
control place A is active, DI1 gives the start and stop commands, and the PID controller gives
the frequency reference. When control place B is active, DI4 gives the start and stop
commands, and AI1 gives the frequency reference.
You can configure all the drive outputs freely in all the applications. There are 1 analogue
output (Output Frequency) and 3 relay outputs (Run, Fault, Ready) available on the basic I/O
board.
See the descriptions of the parameters in Table 1 The Startup wizard.
