4.1.6 EXTRAS AND ADVANCED
Table 19: Monitoring of the advanced values
Index Monitoring value Unit Scale ID Description
V2.6.1 Drive Status Word 1 43
B1 = Ready
B2 = Run
B3 = Fault
B6 = RunEnable
B7 = AlarmActive
B10 = DC current in stop
B11 = DC brake active
B12 = RunRequest
B13 = MotorRegulatorActive
B15 = Brake Chopper Active
V2.6.2 Ready Status 1 78
B0 = Run Enable active
B1 = No fault
B2 = Charge switch closed
B3 = DC voltage OK
B4 = Power unit OK
B5 = Start allowed (Power unit)
B6 = Start allowed (System software)
V2.6.3
Application Status
Word1
1 89
B0 = Run Interlock 1
B1 = Run Interlock 2
B2 = Ramp 2 active
B3 = Reserved
B4 = I/O A control active
B5 = I/O B control active
B6 = Fieldbus control Active
B7 = Local control active
B8 = PC control active
B9 = Preset frequencies active
B10 = Flushing active
B11 = Fire Mode active
B12 = Motor Preheat active
B13 = Quick stop active
B14 = Stopped from keypad
V2.6.4
Application Status
Word2
1 90
B0 = Acc/Dec prohibited
B1 = Motor switch open
B2 = PID running
B3 = PID sleep
B4 = PID soft fill
B5 = Autocleaning active
B6 = Jockey pump
B7 = Priming pump
B8 = Anti-blocking
B9 = Input pressure alarm
B10 = Frost protection alarm
B11 = Overpressure alarm
B14 = Supervision 1
B15 = Supervision 2
V2.6.5
DIN Status Word 1 1 56
V2.6.6 DIN Status Word 2 1 57
VACON · 120 MONITORING MENU
4
