Vacon 100 flow Applications Manual

The unit of the monitoring value is celsius degrees or fahrenheit degrees, depending on the
'C/F Selection' parameter value.
V2.5.4 TEMPERATURE INPUT 4 (ID 69)
This monitoring value shows the measured value of the temperature.
The unit of the monitoring value is celsius degrees or fahrenheit degrees, depending on the
'C/F Selection' parameter value.
V2.5.5 TEMPERATURE INPUT 5 (ID 70)
This monitoring value shows the measured value of the temperature.
The unit of the monitoring value is celsius degrees or fahrenheit degrees, depending on the
'C/F Selection' parameter value.
V2.5.6 TEMPERATURE INPUT 6 (ID 71)
This monitoring value shows the measured value of the temperature.
The unit of the monitoring value is celsius degrees or fahrenheit degrees, depending on the
'C/F Selection' parameter value.
9.4 EXTRAS AND ADVANCED
V2.6.1 DRIVE STATUS WORD (ID 43)
This monitoring value shows the bit-coded status of drive.
V2.6.2 READY STATUS (ID 78)
This monitoring value shows the bit-coded data about the Ready criteria of the drive.
This data is useful for monitoring when the drive is not in the Ready state.
NOTE!
The values are visible as checkboxes on the graphical display. If a box is selected,
the value is active.
V2.6.3 APPLICATION STATUS WORD 1 (ID 89)
This monitoring value shows the bit-coded statuses of the application.
NOTE!
The values are visible as checkboxes on the graphical display. If a box is selected,
the value is active.
V2.6.4 APPLICATION STATUS WORD 2 (ID 90)
This monitoring value shows the bit-coded statuses of the application.
VACON · 206 MONITORING VALUE DESCRIPTIONS
9
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
