10.14.2 SETPOINTS
P3.13.2.1 KEYPAD SETPOINT 1 (ID 167)
Use this parameter to set the setpoint value of the PID controller when the setpoint source is
'Keypad SP'.
The value of this parameter is given in the selected process unit.
P3.13.2.2 KEYPAD SETPOINT 2 (ID 168)
Use this parameter to set the setpoint value of the PID controller when the setpoint source is
'Keypad SP'.
The value of this parameter is given in the selected process unit.
P3.13.2.3 SETPOINT RAMP TIME (ID 1068)
Use this parameter to set the rising and falling ramp times for the setpoint changes.
Ramp time is the time that is necessary for the setpoint value to change from minimum to
maximum. If the value of this parameter is set to 0, no ramps are used.
P3.13.2.4 PID SETPOINT BOOST ACTIVATION (ID 1046)
Use this parameter to select the digital input signal that activates the boost for the PID
setpoint value.
P3.13.2.5 PID SETPOINT SELECTION (ID 1047)
Use this parameter to set the digital input signal that selects the PID setpoint value to be
used.
P3.13.2.6 SETPOINT SOURCE 1 SELECTION (ID 332)
Use this parameter to select the source of the PID setpoint signal.
The AIs and the ProcessDataIn are handled as percentages (0.00-100.00%) and scaled
according to the setpoint minimum and maximum.
NOTE!
The ProcessDataIn signals use 2 decimals.
If temperature inputs are selected, you must set the values of parameters P3.13.1.5 Process
Unit Min and P3.13.1.6 Process Unit Max to correspond to the the scale of the temperature
measurement board: ProcessUnitMin = -50 °C and ProcessUnitMax = 200 °C.
P3.13.2.7 SETPOINT 1 MINIMUM (ID 1069)
Use this parameter to set the minimum value of the setpoint signal.
P3.13.2.8 SETPOINT 1 MAXIMUM (ID 1070)
Use this parameter to set the maximum value of the setpoint signal.
PARAMETER DESCRIPTIONS VACON · 305
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
10
