Vacon 100 flow Applications Manual

5 PARAMETERS MENU
You can change and edit the parameters in the Parameters menu (M3) at all times.
5.1 GROUP 3.1: MOTOR SETTINGS
Table 27: Motor nameplate parameters
Index Parameter Min Max Unit Default ID Description
P3.1.1.1
Motor Nominal Volt-
age
Varies Varies V Varies 110
P3.1.1.2
Motor Nominal Fre-
quency
8.00 320.00 Hz 50 / 60 111
P3.1.1.3
Motor Nominal
Speed
24 19200 rpm Varies 112
P3.1.1.4
Motor Nominal Cur-
rent
I
H
* 0.1 I
H
* 2 A Varies 113
P3.1.1.5
Motor Cos Phi
(Power Factor)
0.30 1.00 Varies 120
P3.1.1.6
Motor Nominal
Power
Varies Varies kW Varies 116
PARAMETERS MENU VACON · 127
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
5

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
