Vacon 100 flow Applications Manual

Table 28: Motor control settings
Index Parameter Min Max Unit Default ID Description
P3.1.2.2 Motor Type 0 1 0 650
0 = Induction motor
1 = PM motor
2 = Reluctance motor
P3.1.2.3 Switching Frequency 1.5 Varies kHz Varies 601
P3.1.2.4 Identification 0 2 0 631
0 = No action
1 = At standstill
2 = With rotation
P3.1.2.5 Magnetising Current 0.0 2*IH A 0.0 612
P3.1.2.6 Motor Switch 0 1 0 653
0 = Disabled
1 = Enabled
P3.1.2.10 Overvoltage Control 0 1 1 607
0 = Disabled
1 = Enabled
P3.1.2.11 Undervoltage Control 0 1 1 608
0 = Disabled
1 = Enabled
P3.1.2.12 Energy Optimisation 0 1 0 666
0 = Disabled
1 = Enabled
P3.1.2.13 Stator Voltage Adjust 50.0 150.0 % 100.0 659
P3.1.2.15 Rs Voltage Drop 0.00 50.00 % 0.00 662
P3.1.2.16 Ls Voltage Drop 0.00 200.00 % 0.00 673
P3.1.2.17 Motor BEM Voltage 0 Varies V 0 674
Table 29: Motor limit settings
Index Parameter Min Max Unit Default ID Description
P3.1.3.1 Motor Current Limit I
H
*0.1 I
S
A Varies 107
P3.1.3.2 Motor Torque Limit 0.0 300.0 % 300.0 1287
VACON · 128 PARAMETERS MENU
5
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
