Vacon 100 flow Applications Manual

4.1.9 EXTERNAL PID CONTROLLER MONITORING
Table 22: Monitoring of the values of the external PID controller
Index Monitoring value Unit Scale ID Description
V2.9.1 ExtPID Setpoint Varies
As set in
P3.14.1.1
0 (See
5.14
Group
3.14:
External
PID con-
troller)
83
V2.9.2 ExtPID Feedback Varies
As set in
P3.14.1.1
0
84
V2.9.3 ExtPID Error Varies
As set in
P3.14.1.1
0
85
V2.9.4 ExtPID Output % 0.01 86
V2.9.5 ExtPID Status 1 87
0=Stopped
1=Running
2=In dead band (see 5.14 Group 3.14: External
PID controller)
4.1.10 MULTI-PUMP MONITORING
You can use the monitoring values from Pump 2 Running Time to Pump 8 Running Time in
the Multi-pump (single drive) mode.
If you use Multimaster or Multifollower mode, read the value of the pump runtime counter
from the monitoring value Pump (1) Running Time. Read the pump runtime from each drive.
MONITORING MENU VACON · 123
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/
4

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
